SIMATIC HMI KP300 Basic mono PN

  • 7554-5858
  • |
  • 6AV66470AH113AX1
3 piece in stock
Login to order
Don’t have an account? Request account
  • Products Over 6.000 products in stock
  • Order before 17:00 and receive your order the next working day!
  • Need help? Call --- --- or contact us via email at [email protected]

General information

SIMATIC HMI KP300 Basic mono PN SIMATIC HMI KP300 Basic mono PN
Ordercode YESSS
7554-5858
Product code
6AV66470AH113AX1
EAN code
4025515738121
Product group
Graphic panel
Brand
Siemens
Serie
SIMATIC KP300 Basic mono PN
Type
6AV6647-0AH11-3AX1

Product description

Produktbeschreibung

    Simatic HMI KP300 Basic mono PN

    Das SIMATIC HMI KP300 Basic mono PN ist ein kostengünstiges Basic Panel für einfache Visualisierungsaufgaben im maschinennahen Bereich.

    Technische Details:

    • 3 FSTN LCD Display, Schwarzweiß
    • PROFINET Schnittstelle
    • Projektierbar ab WinCC Basic V11/ STEP 7 Basic V11
    • Open Source Software auf beiliegender CD enthalten
    • Verfügbar in Widescreen-Displays: 4", 7", 9" oder 12" Diagonale
    • Kombinierte Tasten- und Touchbedienung mit Gestensteuerung
    • 64.000 Farben für hochauflösende Anzeige
    • Bis zu 100 % dimmbare Helligkeit
    • USB-Interface für Anschluss von Tastatur, Maus oder Barcodescanner
    • Einfache Archivierung sowie Sichern und Wiederherstellen von Daten über USB-Stick

    Kunden Vorteile:

    • Kostengünstige Realisierung einfacher Visualisierungsaufgaben.
    • Perfekte Einstiegsgeräte für kleine Maschinen und Anlagen.
    • Harmoniert ideal mit den Basic Controllern SIMATIC S7-1200.
    • Hohe Flexibilität durch hochkant einbaubare Geräte.
    • Verbesserte Usability durch innovative Bedienoberfläche.

Product specifications

With numeric keyboard
Yes
With alpha numeric keyboard
Yes
Number of HW-interfaces industrial Ethernet
1
Number of interfaces PROFINET
1
Colour display
Yes
Supply voltage DC
19.2 - 28.8 V
Voltage type (supply voltage)
DC
Number of HW-interfaces RS-232
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces RS-485
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces USB
0
Number of HW-interfaces parallel
0
Number of HW-interfaces Wireless
0
Number of HW-interfaces other
0
With SW interfaces
No
Supporting protocol for TCP/IP
Yes
Supporting protocol for PROFIBUS
No
Supporting protocol for CAN
No
Supporting protocol for INTERBUS
No
Supporting protocol for ASI
No
Supporting protocol for KNX
No
Supporting protocol for Modbus
Yes
Supporting protocol for Data-Highway
No
Supporting protocol for DeviceNet
No
Supporting protocol for SUCONET
No
Supporting protocol for LON
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for SERCOS
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for EtherNet/IP
Yes
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for INTERBUS-Safety
No
Supporting protocol for PROFIsafe
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for other bus systems
No
Radio standard Bluetooth
No
Radio standard WLAN 802.11
No
IO link master
No
Mobile communication standard GPRS
No
Mobile communication standard 2G (GSM)
No
Mobile communication standard 3G (UMTS)
No
Number of colours of the display
4
Usable project memory/user memory
1000 KByte
Number of grey-scales/blue-scales of display
0
Number of function buttons, programmable
10
Number of buttons with LED
0
Number of system buttons
10
Touch technology
None
With message indication
Yes
With message system (incl. buffer and confirmation)
Yes
Process value representation (output) possible
Yes
Process default value (input) possible
Yes
With recipes
Yes
Number of password levels
50
With printer output
No
Number of online languages
5
Additional software components, loadable
No
Degree of protection (IP), front side
IP65
Operating temperature
0 - 50 °C
Suitable for rail mounting
No
Wall mounting/direct mounting
No
Suitable for safety functions
No
Width of the front
165 mm
Height of the front
97 mm
Built-in depth
30 mm
Screen diagonal
3.6 inch
Number of pixels, horizontal
240
Number of pixels, vertical
80
