Ceiling-/wall luminaire SCHUCH PRIMO XR

Add to selection
General information
Ordercode YESSS
7275-8758
Product code
107020004
EAN code
4041254343075
Product group
Ceiling-/wall luminaire
Brand
SCHUCH
Serie
PRIMO XR
Type
107 15L34 XR
LED-Rohrleuchte PRIMO XR 24W 3710lm IP68 (3m) IPX9K sym-breitstr 4000K LED-Rohrleuchte PRIMO XR 24W 3710lm IP68 (3m) IPX9K sym-breitstr 4000K Ra≥ 80 Ta -20°C/+40°C L70>100000 h (@ Ta max) L80>70000 h (@ Ta max) 107020004
Product description

LED-Rohrleuchte, PRIMO XR, 24 W, 3710 lm, SKI, IP68 (3m), IPX9K, symmetrisch-breitstrahlend, 4000 K, Ra≥ 80, Ta -20 °C/+40 °C, L70>100000 h (@ Ta max), L80>70000 h (@ Ta max), L90>50000 h (@ Ta 25°C), Rohr PMMA satiniert, Edelstahlrohrschellen im Lieferumfang enthalten, FastConnect (FC), für ungeschützte Außenbereiche (AUS), EAN/GTIN:4041254343075.Extrem schadgasdichte LED-Rohrleuchte für schadgasbelastete Bereiche. Satiniertes, schlagzähes PMMA-Rohr, mit End-/Anschlusskappen verschweißt. Aluminiumreflektor mit hocheffizienten LED-Modulen und EVG mit Überlast- und Kurzschlussschutz. Elektrischer Anschluss über Schnellsteckverbindung (FastConnect), Steckerteil in Anschlusskappe integriert, Buchsenteil beiliegend. Befestigung mittels zweier Edelstahlrohrschellen, im Lieferumfang enthalten.

Product specifications
Suitable for suspended mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
Yes
Suitable for surface mounting
Yes
With light source
Yes
Type of control gear
LED operating device current-controlled
With control gear
Yes
Suitable for emergency lighting
Yes
Nominal voltage
220 - 240 V
Colour temperature
4000 - 4000 K
Housing material
Plastic
Dimming 0-10 V
No
Dimming 1-10 V
No
Housing colour
White
Dimming DALI
No
Suitable for light line configuration
Yes
Dimming DMX
No
Material cover
Plastic matt/satinized
Dimming DSI
No
Suitable for workplace according to EN 12464-1
Yes
Dimming potentiometer (integrated)
No
Type of grid
None
Dimming manufacturer's proprietary system
No
Light distribution
Symmetric
Dimming mains voltage modulation
No
Beam angle
41-80° - Wide beam
Dimming phase cut-off (trailing edge)
No
Light outlet
Direct
Dimming phase cut-on (leading edge)
No
Length
1529 mm
Dimming programmable
No
Width
103 mm
Dimming RF
No
Height/depth
83 mm
Outer diameter
70 mm
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
With movement sensor
Yes
Light distributor
None
With light sensor
Yes
Protection class according to IEC 61140
I
Impact strength
IK06
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
Yes
Covering of the luminaire with thermally insulating material possible
No
Max. system power
24 W
With air slots
Yes
Voltage type
AC
Colour of light
White
Colour rendering index CRI
80-89
Rated ambient temperature according to IEC 62722-2-1
-20 - 40 °C
Filament test according to IEC 60695-2-11
650 °C - 30 s
Power factor
0.9
Type of wiring
Ending
Number of poles
0.9
Conductor cross section
1.5 mm²
Connection type
Plug
Surface protection housing
Untreated
Exchangeable control gear
No
Dimming DALI-2
No
Max. number of luminaires per miniature circuit breaker B16 (MCB)
16
Constant light output (CLO)
No
Photobiological safety according to EN 62471
RG1
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for wall mounting
No
Compatible with Casambi
No
Meets min. EIA lifetime criterion L90 (at 50,000 hours at tq = 25 °C)
No
more specifications
