LED-Feuchtraumleuchte LUXANO 2 25W 43W 3800lm 6200lm IP65 sym-breitstr 4000K

  • 7591-1282
  • |
  • 167000021
123 piece in stock
Login to order
Don’t have an account? Request account
  • Products Over 6.000 products in stock
  • Order before 17:00 and receive your order the next working day!
  • Need help? Call --- --- or contact us via email at [email protected]

General information

LED-Feuchtraumleuchte LUXANO 2 25W 43W 3800lm 6200lm IP65 sym-breitstr 4000K LED-Feuchtraumleuchte LUXANO 2 25W 43W 3800lm 6200lm IP65 sym-breitstr 4000K Ra≥ 80 Ta -20°C/+35°C L80>50000 h (@ Ta max) L70>100000 h (@ Ta ma 002159
Ordercode YESSS
7591-1282
Product code
167000021
EAN code
4041254400730
Product group
Ceiling-/wall luminaire
Brand
SCHUCH
Serie
LUXANO 2
Type
167 15LG2 VARIO

Product description

LED-Feuchtraum-Wannenleuchte, LUXANO 2, 25 W, 43 W, 3800 lm, 6200 lm, SKI, IP65, symmetrisch-breitstrahlend, 4000 K, Ra≥ 80, Ta -20 °C/+35 °C, L80>50000 h (@ Ta max), L70>100000 h (@ Ta max), Wanne PMMA satiniert, Verschluss Edelstahl (1.4310), Gehäuse glasfaserverstärktes Polyester, Farbe grau, 4-stufig einstellbarer Lichtstrom (Achtung: Es sind nur Min, Max-Werte angegeben), EAN/GTIN:4041254400730.LED-Feuchtraum-Wannenleuchte LUXANO 2 mit variabel einstellbarem Lichtstrom. Glasfaserverstärktes Polyestergehäuse, satinierte Abschlusswanne, geschäumte Dichtung und Edelstahlklammern. Lackierter Reflektor mit LED-Modulen und EVG, variable Kabeleinführung und Halteklammern aus Edelstahl zur einfachen und schnellen Montage der Leuchte.

Product specifications

Suitable for suspended mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Lamp type
LED exchangeable
With light source
Yes
Type of control gear
LED operating device current-controlled
With control gear
Yes
Suitable for emergency lighting
No
Nominal voltage
220 - 240 V
Colour temperature
4000 - 4000 K
Housing material
Plastic
Dimming 0-10 V
No
Dimming 1-10 V
No
Housing colour
Grey
Dimming DALI
No
Suitable for light line configuration
Yes
Dimming DMX
No
Material cover
Plastic matt/satinized
Dimming DSI
No
Suitable for workplace according to EN 12464-1
No
Dimming potentiometer (integrated)
No
Type of grid
None
Dimming manufacturer's proprietary system
No
Light distribution
Symmetric
Dimming mains voltage modulation
No
Beam angle
41-80° - Wide beam
Dimming phase cut-off (trailing edge)
No
Light outlet
Direct
Dimming phase cut-on (leading edge)
No
Length
1477 mm
Dimming programmable
No
Width
85 mm
Dimming RF
No
Height/depth
88 mm
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
With movement sensor
No
Light distributor
None
With light sensor
No
Protection class according to IEC 61140
I
Impact strength
IK05
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
Yes
Covering of the luminaire with thermally insulating material possible
No
Max. system power
43 W
With air slots
No
Voltage type
AC
Colour of light
White
Colour rendering index CRI
80-89
Rated ambient temperature according to IEC 62722-2-1
-20 - 35 °C
Filament test according to IEC 60695-2-11
650 °C - 30 s
Power factor
0.9
Type of wiring
Ending
Number of poles
3
Conductor cross section
2.5 mm²
Connection type
Push-in clamp
Surface protection housing
Untreated
Exchangeable control gear
Yes
Dimming DALI-2
No
Max. number of luminaires per miniature circuit breaker B16 (MCB)
22
Max. number of luminaires per miniature circuit breaker C16 (MCB)
36
Constant light output (CLO)
No
Photobiological safety according to EN 62471
RG1
Colour of light adjustable
No
Luminous flux adjustable
Positions
Beam angle adjustable
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for wall mounting
Yes
Compatible with Casambi
No
Meets min. EIA lifetime criterion L90 (at 50,000 hours at tq = 25 °C)
No
