General information
Miniaturrelais RXM, 2 W, 12 A, 24 VDC
Miniaturrelais RXM, 2 W, 12 A, 24 VDC
Ordercode YESSS
0177-8671
Product code
RXM2AB1BD
EAN code
3389119403399
Product group
Switching relay
Brand
Schneider
Serie
Harmony Elektromechanische Relais
Type
RXM2AB1BD
Product description
Harmony Relay. Miniaturrelais RXM als Komponente. Anzahl Kontakte 2, Ausführung Relaiswechsler, Kontaktbelastbarkeit je 12 A. Spulen-Steuerspannung 24 VDC. Mechanische Stellungsanzeige ja, LED-Anzeige nein. Prüftaste zum Testen der Kontakte ja, Prüfhebel zur dauerhaften Umschaltung für Testzwecke ja, Bedienung werkzeuglos. Montage im separaten Stecksockel.
Product specifications
Voltage type for actuating
DC
Drive, polarization
Polarity free
Nominal current
12 A
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
2
With detachable clamps
No
Type of electric connection
Plug-in connection
Rated control supply voltage DC
24 - 24 V
Drive, switching attitude
Mono stable
With forced-guided contacts
No
Type of switch contact
Other
Complete with socket
No
Degree of protection (IP)
IP40
With LED indication
No
Width
21 mm
Height
27 mm
Depth
55 mm
Material of contact surface
Other
Material of contact insert
Other
Material contact
Other
