Interface-Relais RSB, 1 W, 12 A, 240VAC
- 0172-4575
- |
- RSB1A120U7
0
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Interface-Relais RSB, 1 W, 12 A, 240VAC
Interface-Relais RSB, 1 W, 12 A, 240VAC
Ordercode YESSS
0172-4575
Product code
RSB1A120U7
EAN code
3389110257342
Product group
Switching relay
Brand
Schneider
Serie
Harmony Elektromechanische Relais
Type
RSB1A120U7
Product description
Harmony Relay. Interface-Relais RSB als Komponente. Anzahl Kontakte 1, Ausführung Relaiswechsler, Kontaktbelastbarkeit 12 A. Spulen-Steuerspannung 240 VAC. Undurchsichtiges Gehäuse ohne Anzeigen oder Betätigung. Montage im separaten Stecksockel.
Product specifications
Voltage type for actuating
AC
Drive, polarization
Polarity free
Nominal current
12 A
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
1
With detachable clamps
Yes
Type of electric connection
Plug-in connection
Rated control supply voltage AC 50 Hz
240 - 240 V
Rated control supply voltage AC 60 Hz
240 - 240 V
Drive, switching attitude
Mono stable
With forced-guided contacts
No
Type of switch contact
Single contact
Complete with socket
No
Degree of protection (IP)
IP40
With LED indication
No
Width
12.5 mm
Height
29 mm
Depth
19.6 mm
Material of contact surface
Other
Material of contact insert
Other
Material contact
Other
Relay technology category according to IEC 61810-7
RT I
