LED TUBE T8 UNIVERSAL PERFORMANCE 1500 mm 20W 840

Product description

LED tubes for electronic control gear (ECG), electromagnetic control gear (CCG) and AC mains, shatterproof. Product features: LED replacement for classic T8 fluorescent lamps with G13 socket for use in CCG, ECG luminaires or on AC mains. Compatible with conventional and many common electronic control gears (see also compatibility list) and line voltage. Low flicker according to EU 2019-2020 (SVM ≤ 0.4 / PstLM ≤ 1). Lamp tube made of glass with splinter protection. For especially uniform illumination. Mercury-free and RoHS compliant. Type of protection: IP20. Lifetime up to 60,000 h. Product benefits: No bending thanks to glass technology. Quick, simple and safe replacement without rewiring. Energy savings of up to 66 % (compared to T8 fluorescent lamp). Very high resistance to switching loads. High luminous flux for sophisticated lighting tasks. Also suitable for operation at low temperatures. Areas of application: General illumination within ambient temperatures from -20…+45 °C. Illumination of production areas. Traffic zones and corridors. Supermarkets and department stores. Industry. Legal advice: When used to replace a T8 fluorescent lamp the total energy efficiency and light distribution depends on the design of the lighting system.. Safety advice: Operation in outdoor applications in suitable damp-proof luminaires possible according to data sheet and installation instruction.. The operating temperature range of LED tube is restricted. In case of doubt regarding suitability of the application please measure Tc temperature on the product prior to installation.. For operation of LED TUBE T8 UN with a conventional control gear, the existing starter must be exchanged with the including LED starter in the LED tube packaging.. All electrical connections must be made by a qualified person.. Not suitable for emergency lighting..

Product specifications
