General information

A-2Y(L)2Y...ST III BD 6x2x0,8 500 M A-2Y(L)2Y...ST III BD 6x2x0,8 500 M
Ordercode YESSS
1799-7130
Product code
1591152/500
EAN code
4044774745879
Product group
Data and communication cable
Brand
LAPP
Type
Telefonkabel

Product description

Zur Verwendung als Außenkabel für Fernmelde- und Informationsverarbeitungsanlagen gemäß DIN VDE 0816-1. Als Erd- und Röhrenkabel einsetzbar. Zur festen Verlegung und gelegentlichen Bewegung. Für den Außenbereich geeignet. Flexibler Einsatz bei bis zu ‑20 °C möglich. Zur Verwendung als Außenkabel für Fernmelde- und Informationsverarbeitungsanlagen gemäß DIN VDE 0816-1. Als Erd- und Röhrenkabel einsetzbar. Zur festen Verlegung und gelegentlichen Bewegung. Für den Außenbereich geeignet. Flexibler Einsatz bei bis zu ‑20 °C möglich.

Product specifications

Conductor surface
Bare
Diameter conductor
0.8 mm
Number of cores
12
Stranding element
Quad
Material core insulation
Other
Specification core insulation
Polyethylene (PE)
Core identification
Colour
Screen over stranding element
None
Stranding
Other
Screen over stranding
Foil
Longitudinal water blocking cable
Yes
Radial water blocking cable
No
Protective sheath
Other
Material outer sheath
Other
Specification material outer sheath
Polyethylene (PE)
Colour outer sheath
Black
Reaction-to-fire according to EN 13501-6: Class
None
Reaction-to-fire according to EN 13501-6: Smoke production
None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles
None
Reaction-to-fire according to EN 13501-6: Acidity
None
Halogen free according to EN IEC 60754-2
No
Low smoke according to EN IEC 61034-2
No
Oil resistant according to EN IEC 60811-404
No
Oil resistant (according to IEC 60811-404)
No
Circuit integrity
None
Outer diameter approximate
13.5 mm
Min. permitted bending radius, stationary application/permanent installation
135 mm
Permitted cable outer temperature during assembling/handling
-20 - 50 °C
Permitted cable outer temperature after assembling without vibration
-40 - 70 °C
Category
Other
Conductor material
Copper
Core identification according to HD 308 S2
No
Cable geometry
Round
Certified for shipboard application
No
Weight
175 kg/km
Compatible with Grade2TV according to XP-C 90-483
No
Compatible with Grade3TV according to XP-C 90-483
No
