Unterputz Wandleuchten-Anschlussdose, 60 x 32 x 30 mm, mit Deckel
- 0057-2905
- |
- 1048-00
150
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Unterputz Wandleuchten-Anschlussdose, 60 x 32 x 30 mm, mit Deckel
Unterputz Wandleuchten-Anschlussdose, 60 x 32 x 30 mm, mit Deckel
Ordercode YESSS
0057-2905
Product code
1048-00
EAN code
4013456130005
Product group
Box/housing for built-in mounting in the wall/ceiling
Brand
KAISER
Serie
Unterputz
Type
1048-00
Product description
Wandleuchten-Anschlussdose (1048-00). Installationsart: Basis-Installation | Länge: 60 mm | Breite: 32 mm | Tiefe: 30 mm | Anwendungsgebiet: Für Leitungsauslässe | Anwendungsgebiet: Für Wandleuchten
Product specifications
Mounting method
Flush-mounted
Shape
Other
Provided with revolving ring
No
Airtight
No
Couplable
No
With screws
No
Construction type
Cable junction box
Model
Single
Equipped with
None
Length
60 mm
Depth
30 - 30 mm
Width
32 mm
Inner depth
31.2 mm
Mounting switching equipment
Screwing
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
For tube diameter
20 mm
Housing feed-through by nozzle
No
Suitable for cable diameter
114 - 114 mm
Housing feed-through by step membrane
No
Pipe locking
Yes
Inlet from the rear
Yes
Number of inlets
4
Material
Plastic
Pipe locking optional
No
Halogen free
Yes
Colour
White
Number of included spouts
0
Degree of protection (IP)
IP2X
Cover attachment
Snapped on
Sealable
No
Circuit integrity
None
With screening
No
Max. conductor cross section
2.5 mm²
Cover model
Blind cover
Transparent cover
No
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
Special application
None
Number of non-adjustable device fixing lugs
0
Number of adjustable device fixing lugs
0
With partition panel
No
Compliant with BS 4662
No
