Main switch for distribution board Hager
Add to selection
General information
Ordercode YESSS
2970-1894
Product code
SBM216
Product group
Main switch for distribution board
Brand
Hager
Type
SBM216
Ausschalter 16A 1S+N 250V AC Leuch. 1PLE
Ausschalter 16A 1S+N 250V AC Leuch. 1PLE
Product description
Ausschalter 16A 1 Schließer + Neutral 250V AC mit Leuchtmelder 1PLE.Ausschalter mit LED Meldeleuchte nach DIN EN 60669-1 (VDE 0632-1), DIN EN 60669-2-4 VDE 0632-2-4, DIN EN IEC 60947-3 VDE 0660-107 mit VDE Zeichen, Beschriftungsmöglichkeit direkt am Gerät und geeignet zum nachträglichen Anbau von Zusatzeinrichtungen.
Product specifications
Switching function
Off switch with control lamp
Number of poles
2
Rated current
16 A
Rated voltage
230 V
Min. rated voltage
230 V
Rated switching capacity
0.338 kA
Short-circuit breaking capacity (Icw)
0.24 kA
Voltage type
AC
With signal lamp
Yes
Colour calotte
Other
Lamp type
LED
Lamp socket
Other
Max. lamp power
0 W
Width in number of modular spacings
1
Built-in depth
68 mm
Degree of protection (IP)
IP20
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
0
Number of contacts as change-over contact
0
