General information
Ordercode YESSS
0307-1968
Product code
216533
EAN code
04015082165338
Product group
Control circuit devices combination in enclosure
Brand
Eaton
Housing, Pushbutton actuators, Indicator lights, Enclosure, momentary, Housing, Pushbutton actuators, Indicator lights, Enclosure, momentary,
Product description

Housing, Product range: RMQ-Titan, Complete unit, Design: Enclosure, momentary, Connection type: Screw connection, Description: Indicator light, white, LED element, 85 - 264 V AC, Number of locations: 2 Qty., Color Enclosure covers: Grey, Color RAL Value: RAL 7035, Degree of Protection: IP66, IP67, IP69K, Connection to SmartWire-DT: no, Contacts N/C = Normally closed: 2 NC, Contacts N/O = Normally open: 2 N/O, Contacts Notes = safety function, by positive opening to IEC/EN 60947-5-1, Actuator travel and actuation force as per DIN EN 60947-5-1, K.5.4.1: mm 4.8, Maximum travel: mm 5.7, Minimum force for positive opening: N 15 , Front dimensions: 153 x 80, Standards: IEC/EN 60947, VDE 0660, Mounting position: As required

Product specifications
Number of command positions
3
Number of push buttons
2
Number of indicator lights
1
Suitable for emergency stop
No
Degree of protection (IP)
IP67/IP69K
Number of key switches
0
Number of selector switches
0
Number of mushroom-shaped push-buttons
0
Rated control supply voltage at AC 50 Hz
85 - 264 V
Rated control supply voltage at AC 60 Hz
85 - 264 V
Rated control supply voltage at DC
0 - 0 V
Colour housing cover
Grey
Material housing
Plastic
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
2
Number of contacts as change-over contact
0
Degree of protection (NEMA)
4X, 13
Colour housing
Grey
