Phase busbar Eaton
Add to selection
General information
Ordercode YESSS
0306-3085
Product code
291485
EAN code
04015082914851
Product group
Phase busbar
Brand
Eaton
EV busbars 3Ph., 6.5HP, for auxiliary contact unit
EV busbars 3Ph., 6.5HP, for auxiliary contact unit
Product description
Busbars: flashovers are minimized Use of end caps not required Saves 30% of the assembly time
Product specifications
Number of phases
3
Number of poles
3
Suitable for number of devices
2
Module width
0 mm
Cross section
16 mm²
Length
33 mm
Rated permanent current Iu
80 A
Type of electric connection
Fork
Insulated
Yes
Rated surge voltage
4 kV
Conditioned rated short-circuit current Iq
25 kA
Max. rated operation voltage Ue
415 V
Rated short-time withstand current lcw
0 kA
Suitable for devices with N-conductor
No
Suitable for devices with auxiliary switch
Yes
Can be cut to size
No
Width in number of modular spacings
6
Colour
Other
