General information
Position switch, Adjustable roller lever, Complete unit, 1 N/O, 1
Position switch, Adjustable roller lever, Complete unit, 1 N/O, 1 NC,
Ordercode YESSS
0306-9358
Product code
106790
EAN code
4015081065578
Product group
End switch
Brand
Eaton
Serie
Moeller series
Type
LS-S11/RLA
Product description
Position switch, Basic function: Position switches, Safety position switches, Part group reference: LS(M)-…, Product range: Adjustable roller lever, Degree of Protection: IP66, IP67, Features: Complete unit, Ambient temperature: -25 - +70 °C, Contacts N/O = Normally open: 1 N/O, Contacts N/C = Normally closed: 1 NC, Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Positive opening (ZW): yes, Color Enclosure covers: Yellow, Housing: Insulated material, Connection type: Screw terminal, Standards: IEC/EN 60947
Product specifications
Width sensor
31 mm
Diameter sensor
0 mm
Switching function
Slow-action switch
Output electronic
No
Gehäuse gemäß Norm
Other
Rated operation current Ie at AC-15, 24 V
6 A
Height of sensor
61 mm
Length of sensor
33.5 mm
Rated operation current Ie at AC-15, 125 V
6 A
Rated operation current Ie at AC-15, 230 V
6 A
Rated operation current Ie at DC-13, 24 V
3 A
Rated operation current Ie at DC-13, 125 V
0.8 A
Switching function latching
No
Rated operation current Ie at DC-13, 230 V
0.3 A
Forced opening
Yes
Number of safety auxiliary contacts
1
Number of contacts as normally closed contact
1
Number of contacts as normally open contact
1
Number of contacts as change-over contact
0
Type of interface
None
Type of interface for safety communication
None
Construction type housing
Cuboid
Housing material
Plastic
Coating housing
Other
Type of control element
Adjustable roller lever
Type of electric connection
Cable entry metrical
Alignment of the control element
Roller cam crossed
With status indication
No
Suitable for safety functions
Yes
Explosion safety category for gas
None
Explosion safety category for dust
None
Ambient temperature during operating
-25 - 70 °C
Degree of protection (IP)
IP66/IP67
Degree of protection (NEMA)
Other
