Add to selection
Auxiliary contact module, 2 pole, Ith= 16 A, 1 N/O,
- 0305-9533
- |
- 101371
2
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Auxiliary contact module, 2 pole, Ith= 16 A, 1 N/O,
Auxiliary contact module, 2 pole, Ith= 16 A, 1 N/O, 1 NC, Side mounted
Ordercode YESSS
0305-9533
Product code
101371
EAN code
4015081013067
Product group
Auxiliary contact block
Brand
Eaton
Serie
Moeller series
Type
DILM32-XHI11-S
Product description
Auxiliary contact module, with interlocked opposing contacts, Function: for standard applications, 2 pole, Connection technique: Screw terminals, Rated operational current AC-15 220 V 230 V 240 V: Ie= 4 A, Rated operational current AC-15 380 V 400 V 415 V: Ie= 4 A, Contacts N/O = Normally open: 1 N/O, Contacts N/C = Normally closed: 1 NC, Mounting type: Side mounted, For use with: DILM17…, DILM25…, DILM32…, DILM38…, DILMF8…, DILMF11…, DILMF14…, DILMF17…, DILMF25…, DILMF32…, Type: Side-mounting auxiliary contacts
Product specifications
Mounting method
Side mounting
Number of contacts as change-over contact
0
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
1
Number of fault-signal switches
0
Type of electric connection
Screw connection
Model
Clip-on
Lamp holder
None
Rated operation current Ie at AC-15, 230 V
6 A
