Ceiling-/wall luminaire Dotlux
Add to selection
General information
Ordercode YESSS
4974-4378
Product code
3109-150120
EAN code
4260210320954
Product group
Ceiling-/wall luminaire
Brand
Dotlux
Type
3109-150120
DOTLUX LED moisture-proof luminaire MISTRALxtreme 1500mm 60W 5000K IP66
DOTLUX LED moisture-proof luminaire MISTRALxtreme 1500mm 60W 5000K IP66
Product description
Housing made entirely of aluminum and glass, making it extremely weather-resistant and suitable for outdoor use5-pole through-wiring at the factory enables quick installationMicroprismatic toughened safety glass for glare-free light distribution (UGR mounting accessories supplied (ceiling/wall or suspended mounting)Mounting brackets can be freely positioned on the luminaire - existing fixing points on the ceiling and wall can still be usedMetal cable gland and metal cover includedImpact resistance IK08Suitable for central batterySustainable product design thanks to easily replaceable components
Product specifications
Suitable for suspended mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Lamp type
LED exchangeable
With light source
Yes
With control gear
Yes
Suitable for emergency lighting
Yes
Colour temperature
5000 - 5000 K
Housing material
Other
Dimming 0-10 V
No
Dimming 1-10 V
No
Housing colour
Silver
Dimming DALI
No
Suitable for light line configuration
No
Dimming DMX
No
Material cover
Plastic matt/satinized
Dimming DSI
No
Suitable for workplace according to EN 12464-1
Yes
Dimming potentiometer (integrated)
No
Type of grid
None
Dimming manufacturer's proprietary system
No
Light distribution
Symmetric
Dimming mains voltage modulation
No
Beam angle
> 80° - Extreme wide beam
Dimming phase cut-off (trailing edge)
No
Light outlet
Direct
Dimming phase cut-on (leading edge)
No
Length
1520 mm
Dimming programmable
No
Width
112 mm
Dimming RF
No
Height/depth
92 mm
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
With movement sensor
No
Light distributor
None
With light sensor
No
Protection class according to IEC 61140
I
Impact strength
IK08
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
Yes
Covering of the luminaire with thermally insulating material possible
No
Max. system power
60 W
With air slots
No
Voltage type
AC/DC
Rated lifetime L70/B50 at 25 °C
100000 h
Colour of light
White
Colour rendering index CRI
80-89
Rated ambient temperature according to IEC 62722-2-1
40 - 50 °C
Suitable for lamp power
60 - 60 W
Type of wiring
Loop-through wiring included
Connection type
Push-in clamp
Exchangeable control gear
No
Dimming DALI-2
No
Colour consistency (McAdam ellipse)
SDCM6
Max. number of luminaires per miniature circuit breaker B16 (MCB)
24
Max. number of luminaires per miniature circuit breaker C16 (MCB)
40
Unified Glare Ratio (UGR)
19
Colour of light adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Suitable for wall mounting
Yes
Energy efficiency class of the light source according to EU regulation 2019/2015
Not required
Compatible with Casambi
No
