General information
Tubular cable lug Cu, version for fine-stranded conductors DIN 0295,
Tubular cable lug Cu, version for fine-stranded conductors DIN 0295, 150 mm² M 8, 1 piece
Ordercode YESSS
183338
Product code
183338
EAN code
4021103833384
Product group
Tubular cable lug for copper conductors
Brand
Cimco
Serie
Rohrkabelschuhe Cu, für feindrähtige Leiter
Type
183338
Product description
Tubular cable lugs Cu. Design for fine stranded conductors according to DIN 0295 and IEC 228. Technical data - Material: Cu-ETP according to DIN EN 13600 - Flared cable entry "Easy Entry"- Surface: electro tin plated, other surfaces on request - Annealed to copper hardness F20. Design: Cross-section: 150 mm²; Bolt-⌀: 8 mm; W: 33; ⌀i: 18; ⌀e: 23; C1: 17; C2: 18; a: 35,5; L: 89; Weight per 100 pcs.~kg: 11,26; Packs per pc. 1
Product specifications
Nominal cross section
150 mm²
Bolt dimension (metric)
8
Insulated
No
Material
Copper
Connecting angle
180° (horizontal)
Flange shape
Ring shape
Slender flange model
No
With sight-hole
No
Surface protection
Tinned
Number of mounting holes
1
AWG size
300 kcmil
Suitable for solid conductors
No
Suitable for stranded conductors
No
Suitable for fine strand conductors
Yes
Suitable for extra fine-strand conductors
Yes
