Anlegetemperaturfühler, NTC 2K25
Add to selection
General information
Ordercode YESSS
1964-6758
Product code
G9050270
EAN code
4050528038319
Product group
Sensor (HVAC)
Brand
Alre
Type
ALF-0
Anlegetemperaturfühler, NTC 2K25
Anlegetemperaturfühler, NTC 2K25
STOCK
IN STOCK
0
piece
Product description
Die Anlegetemperaturfühler ALF werden zur Temperaturerfassung an Leitungen, Rohren oder Heizungsträgern eingesetzt. Zur besseren Temperaturübertragung zwischen Rohr und Anlegefühler wird die Verwendung von Wärmeleitpaste empfohlen.
Product specifications
With mounting material
Yes
Suitable for tube mounting
Yes
With housing
Yes
Cover attachment
Bayonet latch
Sensor element inside housing
Yes
Sensor element outside housing
No
Fixed cable to sensor
No
Active temperature measurement
No
Passive temperature measurement
Yes
Temperature measuring range
-30 - 70 °C
Sensor type
Other
Type of power supply
None
Type of electric connection
Screw connection
Max. ambient humidity (non-condensing)
95 %
Ambient temperature
-30 - 70 °C
Explosion-proof
No
Degree of protection (IP)
IP65
Housing height
64 mm
Housing width
58 mm
Housing depth
34 mm
Housing colour
White
